Isostatic Pressure Graphite
Isopressing high-purity graphite is made into low ash raw material by high temperature graphitizing and ash handling treatment. Mainly used as discharge electron tube, thyratron, graphite block for mercury arc rectifier, graphite boat, pot and electric heating element for semiconductor technology, graphite utensil used for metal gasification, continuous casting, graphite mould for pressure agglomeration and graphite electrode processing.

In addition, in order to meet requirement from all high and new technology industry, we supply imported isotropy graphite for choice.

Characteristic

  1. high density,

  2. high intensity,

  3. high purity.

Advantages

  1. High Temperature Resistance

  2. Thermal Conductivity

  3. Corrosion Resistance

  4. Special Thermal Shock Resistance

Our company supply quality certificate: including our company name, buyer name, product name. model, specification, batch number, date of production, number of package, product standard number, Physical and chemical indicators, Verification Department signature.


FAQ

1.When can i get the price?

We usually quote within 24 hours after getting your detailed requirements,like size,quantity etc. .

If it is an urgent order, you can call us directly.

2. Do you provide samples?

Yes, samples are available for you to check our quality.

Samples delivery time will be about 3-10 days.

3.What about the lead time for mass product?

The lead time is based on the quantity,about 7-12days.For graphite product,apply Dual-use items

license need about 15-20working days.

4.What is your terms of delivery?

We accept FOB, CFR, CIF, EXW, etc. You can choose the most convenient way for you. Besides that,

we can also shipping by Air and Express.

5.Product packaging?

We are packed in wooden cases, or according to your requirements.

6.Notice

The actual price will depends on raw materials,exchange rate ,wage and your order quantity .

Hope to cooperation with you,Thanks !


Items

Unit

Specification

Grain Size

mm

0.012-0.045

Bulk Density

g/cm3

1.78-1.88

Resistivity

μΩ•m

10-14

Flexural Strength

Mpa

28-50

Compressive Strength

Mpa

60-100

C.T.E

×10-6/

3.2-5.2

Ash

%

0.05-0.1

Products can be processed as order requirement or drawings.

Product Name

Industry

Application

Crucible,Boat,Dish,etc.

Metallurgy

Melting,refining and analysis

Dies,Molds,Ingot Chassis,etc.

EDM graphite electrodes,semiconductor manufacturing,iron,steel and nonferrous metal making,continuous casting,metallurgy pressing machine

Graphite Roller,etc.

Heat treatment of steel plate in furnace

Conduit,Skateboard,etc.

Aluminum molding

Graphite Pipe

Guard pipe for measuring temperature,blowpipe,etc

Graphite Block

Masonry furnace and other heat resistance material

Chemical Equipment

Chemistry

Heat exchanger,reaction tower,distillation columns,absorption equipment,centrifugal pumps,etc

Electrolytic Plate

Salt solution and baking molten salt electrolyte

Electrolytic Mercury

NaCI electrolyte

Grounded Anode

Electrical anticorrosion

Motor Brush

Electricity

Commutator,slipping ring

Current Collector

Skate,slide,trolley

Contact

Switches,relays

Mercury Ferry And Electronic Pipe

Electronics

Anode,grid pole,repeller pole,ignition pole of the Mercury rectifier and anode,grid electrode

Graphite Bearing

Machinery

High temperature resistance sliding bearing

Sealing Element

Sealing ring,stuffing box seal,packing seal

Product Element

Braking in plane and vehicle

Nuclear Graphite

Nuclear Power

Deceleration materials,reflective materials,shielding materials,nuclear fuel,support devices,etc


Packing:

Plywood case packing, interspace is filled with materials in order to avoid shaking.
